Consew 206RBL-30" Longarm Compound Walking Foot & Needle Feed Industrial Sewing Machine
Consew 206RBL-30" Longarm Compound Walking Foot & Needle Feed Industrial Sewing Machine Product Details.
Price is for machine head ONLY. Does not include table or motor.
Features:
Work Space 30"
Single Needle Triple Feed
Up To 1800 Stitches Per Minute
Single Needle Lockstitch
Safety Clutch For Timing
Finger & Belt Guards & 69 Thread
Upholstry Sewing Machine
Needle size 135x17 is for Heavy, canval & vinyl
Needle size 135x16NW is for leather
Uses Superior 18034 M Bobbins
Specifications:
1800 stitches per minute
Safety clutch with push button re-engagement
Large horizontal hook
Reverse feed
9/16" clearance under foot
Heavy-duty single needle lockstitch
Compound feed and alternating presser feet (walking foot and needle feed)
Centralized Arm Lubrication
Reservoir-Oiled Hook with Micrometric Control Valve
Three stitches to the inch
Large bobbin
Large horizontal axis hook
Bobbin can be changed without removing object being sewn
Thread release finger (for heavy thread)
High presser foot lift - NOW 9/16" (14mm)
Reverse stitching
All gear driven hook mechanism
Stitches per minute - 1800 max
Simple adjustment permits raising and lowering of the center foot which allows for sewing different thickness of material and thus assures positive stitching
Needle feed and walking foot mechanism identical to Consew Model 226RB-30 including take-up and tension
Standard feet and attachments interchangeable with Consew Models 226RB-30
Uses same welt feet and needles as Consew Models 226RB-30 and similar types
Needle plate, foot and feed dog can be changed for special operations
Standard attachments easily installed
Compound feed, walking foot mechanism insures even feeding of material
For sewing light to heavy-weight materials such as leather, vinyl, upholstery, synthetics, canvas and various coated and laminated products
Designed for stitching such products as auto, boat and furniture upholstery, tarpaulins, covers, sails, tents, camping trailer covers, awnings, umbrellas, tops, bags, luggage, handbags, travel ware accessories, sports and camping equipment, wearing apparel, outdoor clothing, canvas shoes, slippers, orthopedic appliances etc.
Maximum stitch length: 2 1/2 s.p.i. (10 mm)
Maximum stitches per minute: 1800
Presser foot lift by hand: 1/4" (6.5 mm)
Presser foot lift by foot: 5/8" (16 mm)
Needle bar stroke: 1-5/16" (33 mm)
Stitch length maximum: 3.2 SPI (8 mm)
Needle: 135 x 17
Bobbin metal: 18034
Bobbin pre-wound: M
Bed size: 7" x 33-9/16" (178 x 852 mm)
Work space: 30" (789 mm)
Stitch type: 301
